Quick Specs:
  • Color: Stainless Steel
  • Width: 36"
  • Height: 28 7/8"
  • Depth: 20"
  • Type: Downdraft
  • CFM: 600
  • Blower Type: Internal
  • Venting Type: Ducted
  • Voltage: 120
  • Amps: 15
0 People watching this product now!

JennAir JXD7036YS 36 inch Euro-Style Stainless Telescoping Downdraft Ventilation with 600 CFM, Hidden Slide Controls, Automatic Shutoff When Retracted, Dishwasher Safe Mesh Filter, in Stainless Steel

SKU: JXD7036YS
$1,749.00
$1,749.00
Purchase & earn 1,749 points!

Purchase & earn 1,749 points!
  • Delivery ETA
  • Warranty:
  • Free 30-Day returns
Quick Specs:
  • Color: Stainless Steel
  • Width: 36"
  • Height: 28 7/8"
  • Depth: 20"
  • Type: Downdraft
  • CFM: 600
  • Blower Type: Internal
  • Venting Type: Ducted
  • Voltage: 120
  • Amps: 15
0 People watching this product now!
Description

Features:

Euro-Style Stainless 36″ Telescoping Downdraft Ventilation
This Jenn-Air® luxury telescoping downdraft ventilation offers minimal design and powerful performance right at the cooking surface. The sleek telescoping downdraft vent appears at the touch of a button, and elegantly retracts back into the countertop when not in use.

600 CFM High-Performance Blower
A single centrifugal blower motor design allows the ventilation system to operate at up to 600 CFM to quickly remove smoke, steam and cooking odors.

14-Inch Rise
Vent rises a full 14 inches (35.6cm), so it’s far enough above the cooktop to capture steam from tall stockpots and other cookware.

Reversible Motor Box
Designed for flexibility, the reversible motor box can be positioned to face the front or back of cabinets to accommodate more installation options.

Four Fan Speed Settings
Four different settings on this luxury telescoping downdraft ventilation allow you to control the ventilation level for optimum performance and energy efficiency.

Dishwasher-Safe Premium Mesh Filters
These aluminum mesh filters, which effectively capture smoke, grease and cooking odors as they’re drawn through the hood, can be easily cleaned in the dishwasher.

6-Inch Round Exterior Venting
The 6-inch round exterior ventilation system allows ductwork to extend through an outer wall or the roof of a home.

3 1/4″ x 10″ Rectangular Exterior Venting
The 3 1â„4″ x 10″ rectangular exterior ventilation system allows ductwork to extend through an outer wall or the roof of a home.

Hidden Slide Controls
This luxury telescoping downdraft ventilation achieves its sleek appearance with controls that are hidden from sight.

Automatic Shutoff When Retracted
This feature provides peace of mind by ensuring that the blower will always be turned off once the hood has been lowered into the countertop.

Integrated Styling
This luxury telescoping downdraft ventilation, which integrates into countertops and islands, allows you to achieve a streamlined look.

Slim Profile
The telescoping downdraft ventilation’s slim profile takes up minimal space on a countertop or island.


Specifications
Brand JennAir

Appearance
Color Stainless Steel
Color Family Stainless Steel

Dimensions
Exterior Width 36"
Width 36"
Depth 20"
Height 28 7/8"
Vertical Rise 14"

Style
Type Downdraft
Fan Yes

Technical Details
Voltage 120
Amps 15
Duct Type Round
Duct Diameter 6"
Duct Length 10"
Duct Width 3 1/4"
Frequency 60 Hz.
Vent Location Side

Features
CFM 600
Filter Type Mesh
Venting Type Ducted
Blower Type Internal
Number of Fan Speeds 4
Specifications
Brand JennAir

Appearance
Color Stainless Steel
Color Family Stainless Steel

Dimensions
Exterior Width 36"
Width 36"
Depth 20"
Height 28 7/8"
Vertical Rise 14"

Style
Type Downdraft
Fan Yes

Technical Details
Voltage 120
Amps 15
Duct Type Round
Duct Diameter 6"
Duct Length 10"
Duct Width 3 1/4"
Frequency 60 Hz.
Vent Location Side

Features
CFM 600
Filter Type Mesh
Venting Type Ducted
Blower Type Internal
Number of Fan Speeds 4
Features
14-Inch Rise
For maximum effectiveness, the telescoping downdraft extends 14 inches from the countertop to efficiently capture smoke, steam and cooking odors while you cook.
Dishwasher-Safe Premium Mesh Filters
These aluminum mesh filters, which effectively capture smoke, grease and cooking odors as they’re drawn through the hood, can be easily cleaned in the dishwasher.
Hidden Slide Controls
This luxury telescoping downdraft ventilation achieves its sleek appearance with controls that are hidden from sight.
