- Color: Stainless Steel
- Width: 36"
- Height: 28 7/8"
- Depth: 20"
- Type: Hood
- CFM: 600
- Blower Type: Internal
- Venting Type: Ducted
- Voltage: 120
- Amps: 15
JennAir JXD7036YS 36 inch Euro-Style Stainless Telescoping Downdraft Ventilation with 600 CFM, Hidden Slide Controls, Automatic Shutoff When Retracted, Dishwasher Safe Mesh Filter, in Stainless Steel
Availability: In Stock (Low)
Availability: In Stock (Low)
Availability: In Stock (Low)
- Color: Stainless Steel
- Width: 36"
- Height: 28 7/8"
- Depth: 20"
- Type: Hood
- CFM: 600
- Blower Type: Internal
- Venting Type: Ducted
- Voltage: 120
- Amps: 15
Features:
Euro-Style Stainless 36″ Telescoping Downdraft Ventilation
This Jenn-Air® luxury telescoping downdraft ventilation offers minimal design and powerful performance right at the cooking surface. The sleek telescoping downdraft vent appears at the touch of a button, and elegantly retracts back into the countertop when not in use.
600 CFM High-Performance Blower
A single centrifugal blower motor design allows the ventilation system to operate at up to 600 CFM to quickly remove smoke, steam and cooking odors.
14-Inch Rise
Vent rises a full 14 inches (35.6cm), so it’s far enough above the cooktop to capture steam from tall stockpots and other cookware.
Reversible Motor Box
Designed for flexibility, the reversible motor box can be positioned to face the front or back of cabinets to accommodate more installation options.
Four Fan Speed Settings
Four different settings on this luxury telescoping downdraft ventilation allow you to control the ventilation level for optimum performance and energy efficiency.
Dishwasher-Safe Premium Mesh Filters
These aluminum mesh filters, which effectively capture smoke, grease and cooking odors as they’re drawn through the hood, can be easily cleaned in the dishwasher.
6-Inch Round Exterior Venting
The 6-inch round exterior ventilation system allows ductwork to extend through an outer wall or the roof of a home.
3 1/4″ x 10″ Rectangular Exterior Venting
The 3 1â„4″ x 10″ rectangular exterior ventilation system allows ductwork to extend through an outer wall or the roof of a home.
Hidden Slide Controls
This luxury telescoping downdraft ventilation achieves its sleek appearance with controls that are hidden from sight.
Automatic Shutoff When Retracted
This feature provides peace of mind by ensuring that the blower will always be turned off once the hood has been lowered into the countertop.
Integrated Styling
This luxury telescoping downdraft ventilation, which integrates into countertops and islands, allows you to achieve a streamlined look.
Slim Profile
The telescoping downdraft ventilation’s slim profile takes up minimal space on a countertop or island.
Specifications | |
| Brand | JennAir |
Appearance | |
| Color | Stainless Steel |
| Color Family | Stainless Steel |
Dimensions | |
| Exterior Width | 36" |
| Width | 36" |
| Depth | 20" |
| Height | 28 7/8" |
| Vertical Rise | 14" |
Style | |
| Type | Hood |
| Mounting Type | Downdraft |
| Fan | Yes |
Technical Details | |
| Voltage | 120 |
| Amps | 15 |
| Duct Type | Round |
| Duct Diameter | 6" |
| Duct Length | 10" |
| Duct Width | 3 1/4" |
| Frequency | 60 Hz. |
| Vent Location | Side |
Features | |
| CFM | 600 |
| Filter Type | Mesh |
| Venting Type | Ducted |
| Blower Type | Internal |
| Number of Fan Speeds | 4 |
| Brand | JennAir |
|---|---|
|
Appearance |
|
| Color | Stainless Steel |
| Color Family | Stainless Steel |
|
Dimensions |
|
| Exterior Width | 36" |
| Width | 36" |
| Depth | 20" |
| Height | 28 7/8" |
| Vertical Rise | 14" |
|
Style |
|
| Type | Hood |
| Mounting Type | Downdraft |
| Fan | Yes |
|
Technical Details |
|
| Voltage | 120 |
| Amps | 15 |
| Duct Type | Round |
| Duct Diameter | 6" |
| Duct Length | 10" |
| Duct Width | 3 1/4" |
| Frequency | 60 Hz. |
| Vent Location | Side |
|
Features |
|
| CFM | 600 |
| Filter Type | Mesh |
| Venting Type | Ducted |
| Blower Type | Internal |
| Number of Fan Speeds | 4 |
